If you haven’t checked out Microsoft’s new WideWorldImporters sample database for 2016, it’s a pretty cool new little database. The database makes it easy to play around with new 2016 features, and it even ships with some cool little executables to run inserts in the “workload-drivers” folder.

I recently put together some code to reproduce a simple deadlock in WideWorldImporters. This isn’t related to the new features at all– I was just exploring the sample database and writing some demos for locking and blocking. Deadlocks are easier to understand when you have hands-on code that you can step through and watch it happen live, rather than just being mystified by it when it happens later!

Setup - Restore WideWorldImporters

All you need to do is download the WideWorldImporters-Full.bak backup (121MB) and restore it to a test instance with Developer Edition running.

Let’s Cause a Deadlock

You will use two session windows to create your deadlock.

In session window #1, run this code:

USE WideWorldImporters;
GO

/* Run the BEGIN tran and the first statement in this session.
We're taking out a lock on the Countries table */
WHILE @@TRANCOUNT > 1 ROLLBACK
BEGIN TRAN

    UPDATE Application.Countries
    SET LatestRecordedPopulation = LatestRecordedPopulation + 1
    WHERE IsoNumericCode = 840;

Leaving that there, open session window #2, and run this code:

SELECT CityName, StateProvinceName, sp.LatestRecordedPopulation, CountryName
FROM Application.Cities AS city
JOIN Application.StateProvinces AS sp on
    city.StateProvinceID = sp.StateProvinceID
JOIN Application.Countries AS ctry on
    sp.CountryID=ctry.CountryID
WHERE sp.StateProvinceName = N'Virginia'

The code in session window #2 should be blocked – you’ll see it sitting there executing.

Back in session window #1, run this:

    UPDATE Application.StateProvinces
    SET LatestRecordedPopulation = LatestRecordedPopulation +1
    WHERE StateProvinceCode=N'VA'
COMMIT
GO

Session window #1 should tell you that 1 row was affected. It’s done!

Look back in session window #2, though. You should see the following message:

Msg 1205, Level 13, State 51, Line 1

Transaction (Process ID 54) was deadlocked on lock resources with another process and has been chosen as the deadlock victim. Rerun the transaction.

 A “deadly embrace”

SQL Server’s deadlock manager woke up, looked around, and saw that our two session windows were stuck. They each were requesting locks that the other session wouldn’t give up– and if the deadlock manager didn’t break the deadlock, they’d be stuck there forever.

I didn’t set the deadlock priority on any of my transactions, so the deadlock manager picked the session that it thought would be the least work to roll back– and it became the victim.

How to learn more about deadlocks

This repro code will get you started. It’s rerunnable: you can keep deadlocking and deadlocking those sessions.

To teach yourself more about how the locks work:

• Run sp_WhoIsActive with @get_locks=1 from a 3rd session window at different points and observe lock grants and waits between the session
• Set up an extended events session to pick up the deadlock graph, reproduce the deadlock, and teach yourself to decode the graph. (Erin Stellato has a free Stairway to Extended Events if you’re just getting started with those.
• What are your options for fixing this deadlock? Test out optimistic locking, query rewrites, setting deadlock priority, and creating indexes to see what works (I’m not saying that all of them do in this case)
• What is Countries_Archive, and why does it show up in the lock graphs?

Happy learning!
